HIGHVOLT receives order from Deutsches Museum in Munich

The Deutsches Museum in Munich has placed an order at HIGHVOLT – including a pulse voltage system. What seems strange at first glance has a highly exciting background.

Under the motto “Everything is science”, the Deutsches Museum in Munich presents the topics of science and technology in a comprehensive and unique way for its visitors. One of the absolute highlights and the number one visitor magnet is the high-voltage installation. For more than 70 years, it has amazed visitors from all over the world with various flashover experiments and impulse voltages of up to one million volts.



This complex and remarkable engineering system has been in operation since 1953 and is now being renovated. In addition to an extensive refurbishment of the building, a brand new system with many new details is being installed - this comes from HIGHVOLT.



The global market leader for high-voltage testing and measurement technology has been awarded the contract for the overall design and integration of the high-voltage demonstration system, including a Van de Graaff generator and two Tesla generators.


HIGHVOLT bekommt Auftrag vom Deutschen Museum in München

Das Deutsche Museum München hat bei HIGHVOLT bestellt – unter anderem eine Impulsspannungsanlage. Was auf den ersten Blick kurios erscheint, hat einen hochspannenden Hintergrund.

Unter dem Motto “Alles ist Wissenschaft” arbeitet das Deutsche Museum in München die Themenkomplexe Naturwissenschaft und Technik umfassend und einzigartig für seine Besucher auf. Zu einem absoluten Highlight und zum Besuchermagnet Nummer eins zählt dabei die Hochspannungsanlage. Diese bringt seit über 70 Jahren bei diversen Überschlags-Versuchen und mit Impulsspannungen von bis zu einer Million Volt Besucher aus aller Welt zum Staunen.



Diese aufwändige und ingenieurtechnisch bemerkenswerte Anlage ist seit 1953 in Betrieb und wird nun erneuert. Neben einer umfangreichen Sanierung des Gebäudes wird eine brandneue Anlage mit vielen neuen Details installiert – diese kommt von HIGHVOLT.



Der Weltmarktführer für Hochspannungsprüf- und Messtechnik hat mit der Auftragserteilung die Gesamtkonzeption und Integration der Hochspannungs-Demonstrationsanlage inklusive einem Van-de-Graaff-Generator und zwei Tesla-Generatoren erhalten.

“Für die Restauration der Hochspannungsdemonstrationsanlage des Deutschen Museums steuert HIGHVOLT nicht nur einen komplett neuen Impulsspannungsgenerator inkl. Spannungsteiler bis 800.000 V bei, auch ein Wechselspannungstransformator bis 300.000 V ist im Lieferumfang enthalten. Zudem kommen neue Steuerungen für die unterschiedlichen Hochspannungsversuche (wie z.B. eine Spitze-Platte-Anordnung oder eine Gleitentladung auf einer Glasplatte) verbunden mit einer umfangreichen Beratungsleistung im Projekt hinzu”, erklärt Uwe Flechtner, Leiter des HIGHVOLT-Projektzentrums.

„Clean-Air“ als wegweisende Zukunftstechnologie

Ganz besonders macht diesen Auftrag der Wechselspannungstrafo – der nämlich erstmals in dieser Art und Weise mit “Clean Air” und nicht mehr mit SF6-Gas als Isolierstoff befüllt sein wird.
SF6-Gas gilt als extrem klimaschädlich, sofern es in die Umwelt gerät. Laut aktueller EU-Verordnung soll das Isoliergas bis spätestens 2032 (Zeitpunkt variiert je nach Produkt und Anwendung bzw. Bestand) aus gasisolierten Schaltanlagen verschwinden. Das von HIGHVOLT zukünftig verwendete "Clean Air" besteht zu etwa 20 Prozent aus Sauerstoff und zu 80 Prozent aus Stickstoff, benötigt aber für die Isoliereigenschaft einen viel höheren Druck als SF6-Gas. Die Besonderheit und Herausforderung für die HIGHVOLT-Ingenieure besteht darin, die Module neu zu konstruieren, um den veränderten Anforderungen gerecht zu werden.

“Es ist für HIGHVOLT einer der ersten Schritte in eine neue hochspannende Welt der Prüftechnik, da neben öl- und SF6-isolierten Geräten nun erstmals ein Transformator mit synthetischer Luft als Isoliermedium zum Einsatz kommen wird. Wir steigen mit diesem Projekt direkt in den Spannungsbereich von 300.000 V ein und betrachten dies als Bewährungsprobe für einen sich wandelnden Produktmix, welcher über die nächsten Jahre sukzessive den globalen SF6-Ausstieg, hin zu alternativen Isoliergasen mitbegleiten wird”, sagt Enrico Bilinski, Teamleiter Transformatoren & Generatoren bei HIGHVOLT.

Hochspannungsversuchsanlage für den Umbau geschlossen

Der entsprechende Museumsteil im Deutschen Museum in München bleibt seit Mitte 2022 bis zur Fertigstellung der Arbeiten 2028 zum großen 125. Jubiläum der Museumsgründung geschlossen. Bei Sanierung und Umbau der Halle ist das renommierte Architekturbüro Holzer Kobler Architekturen involviert, Projektierung und Technik kommt exklusiv von HIGHVOLT.

“For the restoration of the high-voltage demonstration system, HIGHVOLT is not only supplying a completely new impulse voltage generator including voltage divider up to 800,000 V, an AC transformer up to 300,000 V is also included in the scope of delivery. In addition, new control systems for the various high-voltage experiments (such as a tip-plate arrangement or a sliding discharge on a glass plate) are being added to the project along with comprehensive consulting services,” explains Uwe Flechtner, Head of the HIGHVOLT Project Center.

“Clean air” as a pioneering technology of the future

What makes this order particularly special is the AC transformer – which will be filled with “clean air” for the first time in this way and no longer with SF6 gas as an insulating material.
SF6 gas is considered extremely harmful to the climate if it is released into the environment. According to the current EU regulation, the insulating gas is to disappear from gas-insulated switchgear by 2032 at the latest (the date varies depending on the product and application or inventory). The “clean air” used by HIGHVOLT in the future consists of around 20 percent oxygen and 80 percent nitrogen, but requires a much higher pressure than SF6 gas for its insulating properties. The special feature and challenge for the HIGHVOLT engineers is to redesign the modules in order to meet the changed requirements.

“For HIGHVOLT, this is one of the first steps into a new, highly exciting world of testing technology, as a transformer with synthetic air as an insulating medium will now be used for the first time alongside oil- and SF6-insulated devices. With this project, we are entering directly into the voltage range of 300,000 V and see this as a test for a changing product mix, which will gradually accompany the global phase-out of SF6 over the next few years towards alternative insulating gases,” says Enrico Bilinski, Team Leader Transformers & Generators at HIGHVOLT.


High-voltage test facility closed for renovation

The corresponding section of the Deutsches Museum in Munich will remain closed from mid-2022 until the work is completed in 2028 to mark the 125th anniversary of the museum's founding. The renowned architectural firm Holzer Kobler Architekturen is involved in the renovation and conversion of the hall, with HIGHVOLT providing the exclusive project planning and technology.
